TarGun drones offer numerous advantages: they do not require a crew, allowing personnel to focus on more critical tasks. They do not need rest, and their loss is significantly less costly compared to the loss of a traditional truck with a crew. Unmanned systems can automate routine logistics tasks, completing them faster and more efficiently than humans.

Length

1150 mm
Width

898 mm
Height

750 mm
Weight

120 kg
Clearance

170 mm
Category:
Description

Kamikaze / carrier

Control range up to 2000 meters
Load capacity up to 120 kg
Range up to 20 km. Travel time up to 2 hours.
Battery life up to 48 hours.
Remote radio control.
On-board camera for movement control

(optional)

COMBAT CHARACTERISTICS:

  1. MAXIMUM TARGET ENGAGEMENT RANGE – 5 km
  2. TACTICAL NRV OPERATION RADIUS – 1.8 km
  3. RADIO COMMUNICATION RANGE:
    • IN OPEN AREAS (LINE OF SIGHT) – 1.8 km
    • IN RUGGED TERRAIN (HILLS, FORESTS) OR INDUSTRIAL ENVIRONMENTS – 1 km
  4. RANGE (ON A SINGLE BATTERY CHARGE OR FUEL RESERVE):
    • ON HARD SURFACES – 20 km
    • OFF-ROAD – 15 km
  5. CONTINUOUS OPERATION TIME – 1 hour 20 minutes
  6. AUTONOMOUS OPERATION WITHOUT MOVEMENT – 24 hours
  7. MAXIMUM MOVEMENT SPEED:
    • ON HARD SURFACES – 15 km/h
    • OFF-ROAD – 10 km/h
  8. AVAILABLE OPTICAL-ELECTRONIC SURVEILLANCE TOOLS
    • DAY VIDEO CAMERA – 5.8G
  9. PROTECTION LEVEL:
    • BALLISTIC – None
    • ANTI-MINE – None
  10. DEPLOYMENT AND PREPARATION TIME – 2 minutes 30 seconds
    PACK-UP TIME – 2 minutes 30 seconds

TECHNICAL CHARACTERISTICS:

  1. TYPE OF BASE PLATFORM – Load-Bearing Body
  2. NRV CHASSIS TYPE – Wheeled
  3. TYPE OF POWER UNIT – Electric
  4. NRV WEIGHT:
    • FULL – 225 kg
    • UNLADEN – 120 kg
  5. PAYLOAD CAPACITY – 105 kg
  6. RESOLUTION OF TARGET EQUIPMENT
    • DAY CAMERA – 795×596
  7. NRV TRANSPORTATION METHOD – Trunk
  8. CHANNEL CHARACTERISTICS:
    • CONTROL & TELEMETRY – 868–915
    • VIDEO – 5.8
  9. IMPLEMENTED MOVEMENT MODES – Manual
  10. NRV DIMENSIONS – 898×750×1150 mm
  11. OBSTACLES OVERCOME ON DRY GRASSY TERRAIN:
    • MAXIMUM ASCENT ANGLE – 20°
    • MAXIMUM TILT ANGLE – 20°
    • TRENCH WIDTH – 0.3 m
    • VERTICAL WALL HEIGHT – 230 mm
    • MAXIMUM WADING DEPTH (WITH FIRM BOTTOM) – 0.2 m
  12. GROUND CLEARANCE – 170 mm
  13. CAMERA VIEWING ANGLE (CHASSIS CAMERAS):
    • HORIZONTAL PLANE – 175°
    • VERTICAL PLANE – 120°

OPERATIONAL CHARACTERISTICS:

  1. NUMBER OF OPERATORS – 2 persons
  2. WARRANTY PERIOD FOR NRV OPERATION – 1 year
  3. MEAN TIME BETWEEN FAILURES (MTBF) – 500
  4. RESOURCE INDICATORS (OPERATING HOURS OR KILOMETER RANGE BEFORE DECOMMISSION/REPAIR) – 5000
  5. NUMBER OF NRV UNITS PER COMPLEX – 1
  6. NUMBER OF GROUND CONTROL STATIONS PER NRV – 1
  7. OPERATING RANGE:
    • TEMPERATURE (MIN–MAX) – from -10°C to +40°C
    • PRECIPITATION – snow, fog
    • PRESSURE – from 700 to 800 mmHg
    • WIND SPEED – up to 20 m/s
  8. PROTECTION LEVEL (SEALING) – Dust- and water-resistant
  9. TOOLS FOR MAINTENANCE AND MONITORING – Toolkit
  10. NOISE LEVEL DURING MOVEMENT:
    • AT MAXIMUM SPEED – 70 dB
    • AT AVERAGE SPEED – 65 dB

Additional:

  • 5.8g camera with 600mW transmitter, 42-12V converter.

Control set, if you don’t have one (1 for any number of products and FPV drones):

  • Radiomaster TX12 Mark II remote controller
  • Crossfire Micro TX V2 transmitter
  • Remote controller bag
  • 5.8 GHz FPV monitor, 4.3″
  • 5.8 GHz FPV monitor, 7″
